Teknomar 105
The boat is going to be used to harvest scallops in Norwegian waters, with conventional propulsion or stern drive system and inboard diesel engine Volvo Penta D6 350 hp., cruising speed 25 knots, working deck around 11m2, payload 2.500 kg. The vessel should comply with Nordic Boat Standard.

In this project, we were trying to combine yacht elegance with robust capabilities of working boat.
Layout
Main characteristics
LoA – 10,43 m
Beam – 2,98 m
Draft – 0.55 m
Board height on the middle from the keel – 1,817 m
Board height on the middle from the chine –1,267 m
Overall height – 3,128 m
Hull material – Marine grade aluminum 5083
Keel – 14 mm
Bottom – 5 mm
Stiffener structure –5 mm
Board –4 mm
Deck and superstructure – 4mm
Transom – 10mm
Deadrise (stern/middle/bow) – 17/23/57
Displacement – 3000kg light weight without engine
Fuel tank – 680 L
Passenger capacity – 12 persons
Carrying capacity – 2.500 kg
Engine power – 300/600 hp
Max. speed – 33 knots.
Standard specification
  • Top quality marine grade aluminum hull and superstructure (AL 5083).
  • Cockpit, indoor and outdoor floor diamond plate aluminum
  • Wind shield glasses with tinting
  • Back marine door from aluminum with stainless steel lock and hinges
  • Hand rails from aluminum pipe 32 mm.
  • Fuel tank from aluminum 680 L.
  • Mooring cleats made from aluminum 25mm pipe x 6.
  • Isolation. Warm/sound/unsinkable blocks.
  • Pilot console
  • Passenger console with locker
  • Pilot and Passenger seats, vinyl upholstery on pedestal x 2.
  • Anchor locker in bowsection
  • Anchor 20 kg
  • Anchor rope, 30 m
  • Anodes x 2
  • Interior finishing: wall panels covering by carpet and ceiling covering by marine vinyl.
  • Lockers seats in salon with stainless steel latch and hinges x 2
  • Heading ceiling lighting in the salon
  • Steering wheel
  • Ventilation deflector x 2
  • Main switch
  • Fusebox
  • Socket -12 V, USB X 2
  • Main electric control panel, 10 keys
  • Navigation lights: starboard, portside, top, stern, anchor.
  • Charging insulator 100 A
  • Wiring to engines
  • Windshield wiper for pilot side
  • Neck for fuel tank
  • Fuel sensor
  • Fuel indicator
  • Fuel tank air vents
  • Fuel piping
  • Bilge electric pump
  • Bilge electric pump
  • Battery box
  • Battery terminals x 2
  • Fuel filter separator
  • Fender 100 mm
  • Compass
Options
  • Painting custom RAL color
  • Underwater lights
  • Salon table on telescopic pedestal and custom made wooden tabletop ( teak, oak, mahogany)
  • Custom interior upholstery and colors
  • Teak or flexiteak on floor inside
  • Steering wheel in natural leather
  • Additional transom for small outboard up to 30 hp
  • Hydraulic engine control kit
  • Batteries x 3
  • Additional LED lighting in the salon and cockpits
  • Small sliding ventilation windows
  • Searching light
  • LED light in the bow
  • LED navigation lights
  • Autopilot
  • Echo sounder
  • Radar
  • Raymarine AXIOM 12 RV, with sonar 600 W and sonar Real Vision 3D and transom sensor RV-100
  • Audio installation
  • Inverter
  • Shore power
  • Marine horn
  • Windshield wiper for passenger side
  • Heeater 12V , 4 kW
  • Lewmar Pilot hatch
  • Lewmar Passenger hatch
  • Lewmar forward deck hatch
  • Shock Pilot seat with longitudinal slider and turning mechanism
  • Shock Passenger seat with longitudinal slider and turning mechanism
  • Fuel filter separator
  • Stern anchor system: anchor 20 kg, anchor chain 3m, anchor rolls, anchor winch 12V
  • Bow anchor system: anchor 20 kg, anchor chain 3m, anchor rolls, anchor winch 12V
  • Galley: tabletop with sink and gas burner, gas cylinder and hydrophor, neck of the water tank, drinking water tank 32 L
  • Refrigerator
  • Aft cockpit shower
  • Toilet in separated compartment
Price on request
